Route Planning – Job Settings

This article is regarding the enabling of fields related to Detrack Routing.

Steps

1. Navigate to Settings > Job > Fields.
2. Enable the following fields

   Field	Description	Required / Optional	Data Type	Example
   Priority	Jobs with higher priority value have a lower chance of getting dropped from the route, if there is insufficient capacity (e.g. time / load) to perform the job.	Optional.	Integer	1
   Service Time	Time spent at the job location. To account for parking / loading / unloading time etc.. The service time will be added to the ETA Time of the subsequent job in the run.	Optional.	Integer	1
   Run No.	Identifier for the route. Collective set of jobs.	Required	String	Run 1
   Job Sequence	For controlling the index of the jobs to be performed in a route. Jobs with the smallest index to be performed first. Ascending order.	Generated by systems after routing.	Float	1
   ETA Time	Estimated time of arrival when the driver would reach the location.	Generated by systems after routing.	Time	13:30
   Completion Time Window From	Starting time when the job is available to be attempted. The generated ETA Time will be within this Time Window. Default: 00:00.	Optional.	Time	12:00
   Completion Time Window Till	Ending time when the job is available to be attempted. The generated ETA Time will be within this Time Window. Default: 23:59.	Optional.	Time	14:00
   Zone	Jobs assigned a zone can only be assigned to vehicles assigned the same zone or vehicles without a zone. Refer to VRP Zone And Group Assignment.	Optional	String	North
   Group	Jobs belonging to a group can only be assigned to vehicles belonging to the same group or vehicles without a group. Refer to VRP Zone And Group Assignment.	Optional	String	Apple
   Pallets	For capacitated vehicle route planning (cVRP); routes that have a load capacity.	Optional	Integer	10

3. Click Save when done.
